High Resolution TFT LCD Module 3.5 inch 60Hz With UART Port
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Size: | 3.5" | Color: | 65 K |
|---|---|---|---|
| Resolution: | 320*240 | Display Scale: | 4:3 |
| Backlight: | LED | Interface: | RS232/RS485/CMOS/USB |
| CPU: | Cortex | LCD Class: | A |
| High Light: | lcd graphic display module,lcd panel module |
||
High Resolution TFT LCD Module 3.5 inch 60Hz With UART Port
Product Description
1. Used as Touch-controller & TFT-LCD display system
2. Controlled by Any MCU via simple "Command Sets"
3. Low Cost HMI device
Product Parameter
Model: STI035WT-01 (Industrial Type)
|
Physical Parameter |
|
|
Model |
STI035WT-01 |
|
Size (Inch) |
3.5" |
|
Resolution |
320×RGB×240 |
|
Pixel Spacing |
0.1905 mm × 0.0635 mm (H×V) |
|
Color |
65536 colors (16 bit) |
|
Viewing Area |
69.9 mm × 52.53 mm |
|
Overall Dimension |
93.21 mm × 65.3 mm × 13.5 mm(N)/ 15 mm(T) |
|
Net Weight |
85g(N)/ 100g(T) |
|
TFT Panel |
A Level Industry Panel |
|
Touch Screen |
Industry Level 4 wire resistance Or without touch screen is optional. |
|
Backlight Parameter |
|
|
Backlight Type |
LED |
|
Brightness |
250 cd/m2 (Brightness can be adjustable in 100 levels.) |
|
Contrast |
500:1 |
|
Backlight life |
30,000 hours |
|
Viewing Angle |
70°/ 70°/ 50°/ 70° (L/R/U/D) |
|
Working Temperature |
-20°C ~ +70°C |
|
Working Humidity |
60°C, 90% |
|
Storage Temperature |
-30°C ~ +85°C |
|
Screen Mode |
Digital |
|
Performance Parameter |
|
|
CPU |
CortexM3 STM32F103 |
|
LCD Controller |
CPLD EPM240 |
|
Refresh Rate |
60Hz |
|
Picture Switching Speed |
12 ms/picture (83 pictures/s) |
|
Flash Memory |
Standard 128m, Extension 4GB |
|
Memory Amount for picture |
416 images |
|
Interface |
RS232/ TTL UART Interface (Extend to RS485 so on.) |
|
Pictures downloading |
MiniUSB2.0 (12Mbps) & SD card |
|
Voltage Range |
DC5.0V ~ 35V (typical value: 12V) |
|
Power |
0.8W |
|
Test Report |
|
|
MTBF |
4,250,000H |
|
Working Temperature |
-30°C ~ +85°C |
|
Air Humidity |
60°C, 90% |
|
Continuous Vibration Testing |
10-55Hz, 1.5mm, 10G |
|
Impact Acceleration Testing |
6ms, 100G |
|
ESD Testing |
10KV |
|
Radiation Reliability Testing |
44W |
Advantages
|
With CPU & Driving Device |
|
Controlled by Any MCU |
|
Display Picture/ Text/ Curve via Commands |
|
65536 colour TFT display |
|
Touch Screen |
|
RS232/ RS485/ TTL UART Interface & USB port |
|
Wide voltage range |
|
Widely Used in many various Industrial Field |
|
Easy to Use! Powerful Function! Saving Cost and Time! |
|
Used as Touch-controller, TFT-LCD display system, etc. |
Operation
