Rugged Industrial Kiosk Metal Keyboard , Mini Keyboard 304 Stainless Steel

Rugged Industrial Kiosk Metal Keyboard , Mini Keyboard 304 Stainless Steel

Faceplate dimensions: 240*87 mm

Rugged Industrial Kiosk Metal Keyboard , Mini Keyboard 304 Stainless Steel

Application:

This is a mini metal keyboard made of high quality stainless steel ,you could use it on Check-in Kiosk, Boarding Kiosk, Info-Kiosk, Medical Kiosk, Industrial Control Platform, Gaming Machine and etc.

KMY299I-6 Packing list includes 1Xkmy299I-6 keyboard, 1X cable (USB/PS2 port connect to PC )

Dimensions:

Ø  Front Panel: 240 x 87mm

Ø  Overall: 264 x 111mm

Interface: USB or PS/2

Outstanding Features:

Ø  71 keys stainless steel panel mounting keyboard

Ø  Support OS: Windows 95/98/NT/ME/2000/2003/XP/Vista, Linux and Unix

Ø  Mini designed keys: 10x10mm for regular keys

Ø  Customized layout available

Ø  Lettering by etching and inking, or laser technology

Ø  Carbon-on-Gold key switch technology (silicon gel)

Ø  Waterproof and dustproof

Ø  Very rugged vandal proof design

Ø  Can be cleaned with soapy water, disinfectant or other cleaning agents

Material:

Ø  Front Panel: High quality 304# stainless steel

Ø  Keys: High quality 304# stainless steel

Ø  Back panel: Aluminum alloy

Mechanical Data:

Ø  Key trip: 1.5mm

Ø  Key pressure: 0.8～1.6 N

Ø  Lifespan: >2 million operations per key

Ø  Gross Weight: 1.1 KGS

Electrical Data:

Ø  Input Voltage: 5.0VDC±5%

Ø  Electric Current: 10mA

Ø  EMC Emission: EN55022

Ø  ESD Standard: Air Discharge 8KV; Contact Discharge 6KV

Environmental Adaptability:

Ø  Operating Temperature: 0°～+60°

Ø  Storage Temperature: -25°～+80°

Ø  Relative humidity: 30%～90%

Ø  Atmospheric pressure: 60～106 KPa

Reliability:

Ø  MTBF: >20,000 hours

Ø  MTTR: < 30 minutes

Ø  CE, FCC, RoHS, ESD compliant

Ø  Waterproof and Dustproof class: IP65 (front panel)

Ø  Vandal resistant class: IK07
